| Specification | Details |
|---|---|
| Brand / Model | ATLAS RAVEN H311 V1 |
| Chipset | Intel H311 |
| CPU Socket | LGA 1151 |
| Form Factor | Micro-ATX |
| Supported Processors | Supports Intel 6th, 7th, 8th, and 9th Gen Core i9 / i7 / i5 / i3 Supports Pentium and Celeron processors |
| Memory | 2 × DDR4 DIMM slots, Dual-channel support Up to 32 GB capacity DDR4 1866 / 2133 / 2400 / 2666 MHz |
| Storage | 4 × SATA III 6 Gb/s ports 1 × M.2 (NVMe/SATA) slot |
| Expansion Slots | 1 × PCIe 3.0 x16 1 × PCIe x1 |
| Graphics / Video Outputs | 1 × VGA port 1 × HDMI port |
| USB Ports | Rear Panel: 2 × USB 3.0, 4 × USB 2.0, 1 × PS/2 (Keyboard/Mouse combo) Internal Headers: USB 2.0 headers, USB 3.0 headers |
| Audio | Chipset: Realtek® ALC892 / 5.1-channel HD audio Ports: Mic / Line-in / Line-out |
| Networking | LAN: Realtek RTL8111H Speed: 10/100/1000 Mbps (Gigabit Ethernet) Port: 1 × RJ45 |
| Internal Connectors | 24-pin ATX main power 8-pin CPU power CPU fan header, System fan header Front panel audio header Front panel USB headers |
| BIOS | UEFI BIOS Features: EZ Flash, fan control, hardware monitoring |
Sale!
Motherboard, All Products
ATLAS RAVEN H311 V1 Motherboard with DDR4, M.2 for Intel 6th–9th Gen
Original price was: ৳ 5,600.00.৳ 5,460.00Current price is: ৳ 5,460.00.
- Wide CPU Support – Compatible with Intel 6th to 9th Gen processors.
- Fast Memory Performance – Dual-channel DDR4 up to 32GB, speeds reaching 2666MHz.
- Flexible Storage Options – Supports 4 SATA III ports and 1 M.2 slot.
- High-Speed Connectivity – Equipped with USB 3.0, HDMI, Gigabit LAN for fast connections.
- Enhanced Audio System – Realtek ALC892 chipset delivers immersive 5.1-channel HD sound.
The ATLAS RAVEN H311 V1 is a reliable Micro-ATX motherboard built on the Intel H311 chipset, designed to deliver stable performance for home, office, and entry-level gaming systems. Supporting Intel’s 6th, 7th, 8th, and 9th Gen Core i9, i7, i5, i3, along with Pentium and Celeron processors, it offers flexibility across a wide range of builds. With dual DDR4 DIMM slots supporting up to 32GB memory at speeds up to 2666MHz, it ensures smooth multitasking and efficient performance.
For storage, it includes four SATA III ports and one M.2 slot compatible with both NVMe and SATA drives, giving users faster boot times and expanded storage options. Expansion is supported by one PCIe 3.0 x16 slot and one PCIe x1 for additional hardware upgrades.
Connectivity features include USB 3.0, USB 2.0, HDMI, VGA, and Realtek Gigabit LAN. Enhanced with Realtek ALC892 5.1-channel HD audio, the RAVEN H311 V1 offers clear, immersive sound for everyday computing.
